Imager electronics for optical front ends
Empower your optical front end with Simera Sense’s range of imager electronics for your next Earth Observation mission. Our imager electronics are available in snapshot, video, multispectral, and hyperspectral solutions.
Powerful imaging electronics. Your optics.
Bring your own optical front end and pair it with proven, high-performance imager electronics designed to simplify integration and accelerate your path to orbit.
Flexible imaging architectures
Choose from snapshot, video, monochrome, RGB, multispectral, or hyperspectral configurations to match your mission and optical design.
Built for your optical front end
Integrate your own optics with flight-proven electronics engineered to provide the processing, control, and interfaces needed for a complete imaging payload.
High performance, compact SWaP
Get powerful imaging capabilities in compact, SWaP-optimised electronics designed for the demanding constraints of modern Earth Observation missions.
Proven space heritage
Leverage Simera Sense’s flight-proven imaging technology, developed and refined across a growing portfolio of Earth Observation missions.
Two powerful options
xScape-CMV12000 Imager Electronics
Powered by the CMV12000 global shutter image sensor, the xScape-CMV12000 imager electronics will bring exceptional reliability to your Earth observation mission.
12MPixel
Global shutter
Global shutter
8-Bands
Multispectral
Multispectral
32-Bands
Hyperspectral
Hyperspectral
xScape-GMAX3265 Imager Electronics
The 65 MPixel GMAX3265 image sensor brings high-resolution imaging to optical payloads for CubeSats. This high-speed sensor is ideal for snapshot, video, and multispectral imaging.
65MPixel
Global shutter
Global shutter
RGB/Video
Imaging applications
Imaging applications
8-Bands
Multispectral
Multispectral
Two powerful options
xScape-CMV12000 Imager Electronics
Available configurations:
MonoScape
Snapshot electro-optical imaging system employing a monochrome CMV12000 sensor.
TriScape
Snapshot electro-optical imaging system employing a colour sensor with integrated RGB Bayer filter having ‘RGGB’ order.
MultiScape
Line scan electro-optical imaging system providing a panchromatic plus 7 multispectral bands in VNIR.
HyperScape
Line scan electro-optical imaging system providing a panchromatic plus over 400 hyperspectral bands in VNIR.
xScape-XGS45000 Imager Electronics
The powerful imager electronics behind the xScape200 Dual-Use.
Available configurations:
MonoScape
Snapshot electro-optical imaging system employing a monochrome XGS45000 sensor.
TriScape
Snapshot electro-optical imaging system employing a monochrome XGS45000 sensor with integrated RGB Bayer filter having ‘RGGB’ order.
MultiScape
Line scan electro-optical imaging system providing a panchromatic plus 8 multispectral bands in VNIR.
Key features
Key specifications xScape-CMV12000 Imager Electronics
Mass
0.334 kg
Volume
95.88 x 90.17 x 29.4 mm
Pixel depth
10-bit
Power (max)
7.75W
Digital TDI
≤ 16 stages (Multispectral)
≤ 8 stages (Hyperspectral)
≤ 8 stages (Hyperspectral)
Resolution
3072 x 4096 pixels
Pixel size
5.5 μm
Key specifications xScape-XGS45000 Imager Electronics
Mass
0.340 kg
Volume
95.88 x 90.17 x 36.40 mm
Pixel depth
12-bit
Power (max)
8.75W
Digital TDI
≤ 32 stages (Multispectral)
Resolution
8192 x 5460 pixels
Pixel size
3.2 μm
Integrating imager electronics into your mission?
Talk to our team about which xScape imager electronics are the right fit for your optical front end.
